The E-4000 integrated amplifier has emerged from separate amplifier technologies. The preamplifier section features AAVA using ANCC to allow for volume adjustments that maintain high levels of vibrancy. The power amp section employs balanced transmission utilizing the instrumentation amplifier principle to drive noise suppression to its limit. The E-4000 is equipped with a four-fold parallel push-pull configuration of power transistors driven in Class AB in the output stage to extract every last ounce of potential from the speakers and create soundscapes filled with subtlety.

  • Revolutionary AAVA volume control
  • Four-fold parallel push-pull configuration of power transistors driven in Class AB
  • High power output of 180 watts into 8 ohms / 260 watts into 4 ohms
  • Power amplification stage configured as instrumentation amplifier
  • High damping factor of 800
  • Strong power supply with massive high-efficiency toroidal transformer
  • High-voltage, large filtering capacitors
  • Protection circuitry using MOS-FET switches


Continuous Output RMS (20-20,000 Hz): 260 watts per channel into 4 ohms, 180 watts per channel into 8 ohms

Total Harmonic Distortion (20-20,000 Hz): 0.05% with 4 to 16 ohm load

Intermodulation Distortion: 0.01%

Frequency Response: 20 - 20,000 Hz (+0, -0.2 dB)

Damping Factor: 800 (8-ohm load)

Output Voltage and Impedance (Pre Output): 1.51 V, 50 ohms

Gain (High-Level Input > Pre Output): 18 dB

Gain (Main In > Output): 28 dB

Tone Controls Turnover frequency and adjustment range: Bass: 300 Hz ±10 dB (50 Hz), Treble: 3 kHz ±10 dB (20 kHz)

Loudness Compensation: +6 dB (100 Hz)

Attenuator: -20 dB

Output Load Impedance: 4 - 16 ohms

Stereo Headphones: Suitable impedance: 8 ohms or above

Power Requirements: AC 230V 50/60 Hz

Power Consumption: 54 watts, idle 410 watts

Maximum Dimensions (W x H x H): 465 mm x 181 mm x 428 mm

Mass: 24.4 kg (Net)
