GIYA G1 SPIRIT
SEE FOR YOURSELF
| Specifications | Vivid Audio GIYA G1 Spirit |
|---|---|
| Configuration | 4-way 5 driver system |
| Cabinet material | Glass reinforced balsa cored sandwich composite |
| Cabinet colour | Piano Black, Lexus Pearl White, Oyster Matte |
| Bespoke colour | Any PPG automotive colour available on request |
| Drive units | HF: D26 – 26 mm metal dome unit with Tapered Tube loading Mid: D50 – 50 mm metal dome unit with Tapered Tube loading Lower-mid: C125-75s, 125 mm alloy/carbon diaphragm with 75 mm voice coil Bass: 2 x C225-100, 225 mm alloy diaphragm with 100mm voice coil in 45 mm gap |
| Bass loading | Exponentially Tapered Tube enhanced bass reflex |
| Sensitivity | 92 dB @ 2.83 VRMS at 1 m on axis |
| Nominal impedacnce (Ω) | 6 nominal, 3 minimum at 20 KHz no phase shift at Zmin |
| Frequency range (Hz) | -6 dB points: 25 – 36.000 Hz |
| First D26 Break Up mode: | 44.000 Hz |
| Frequency response | 29 – 33.000 Hz +/- 2 dB on reference |
| Harmonic distortion (2nd and 3rd harmonics) |
< 0,3% over frequency range |
| Cross over frequencies (Hz) | 220 – 880 – 3.500 |
| Power handling (music program) watts rms | 1.600 |
| Loudspeaker dimensions | 1.600mm (H) x 440mm (W) x 820mm (D) |
| Net weight | 67,4 kg |
亲眼见证
| 参数 | 规格 |
| 配置 | 四分频 5 单元系统 |
| 箱体材质 | 玻璃增强轻木芯三明治复合材料 |
| 箱体颜色 | 钢琴黑、雷克萨斯珍珠白、牡蛎哑光 |
| 定制颜色 | 可根据需求提供任何 PPG 汽车颜色 |
| 单元配置 | 高音：D26 – 26mm 金属球顶单元，锥形管加载 |
| 中音：D50 – 50mm 金属球顶单元，锥形管加载 | |
| 低中音：C125-75s，125mm 合金/碳纤维振膜，75mm 音圈 | |
| 低音：2 × C225-100，225mm 合金振膜，100mm 音圈，45mm 磁隙 | |
| 低音加载方式 | 指数锥形管增强低音反射式 |
| 灵敏度 | 92 dB @ 2.83 VRMS，1 米轴向测量 |
| 标称阻抗 | 6Ω（标称），最低 3Ω（20kHz 处无相移） |
| 频率范围 | -6 dB 点：25Hz – 36,000Hz |
| 高音单元首个分裂模式 | 44,000Hz |
| 频率响应 | 29Hz – 33,000Hz（参考范围 ±2 dB） |
| 谐波失真 | <0.3%（2 次和 3 次谐波，覆盖整个频率范围） |
| 分频点 | 220Hz – 880Hz – 3,500Hz |
| 功率承受 | 1,600 瓦 RMS（音乐信号） |
| 扬声器尺寸 | 1,600mm（高）× 440mm（宽）× 820mm（深） |
| 净重 | 67.4kg |
