THE SONUS FABER SIGNATURE STYLE

The idea of the dual curvature of the cabinet sides, firstly conceptualized with the Sonus faber and evolved in Aida, is here enhanced thanks to a new design that reinvents the ``lyra`` outline merging two separate identities that cooperate inside the same shape.

FROM THE SONUS FABER ONWARDS

Ideas and patents developed within the Sonus faber, at first, and Aida, later, are integrated into this extraordinary loudspeaker system. The driver units technology, designed and developed by Sonus faber, sets a step forward in the technological innovation.

FEATURES

Lilium appearance reveals its essential duality, characterized by two separates acoustic chambers.
The challenge of this projects is to achieve a new unique synthesis starting from an ontological division

THE TOP

Made of tempered glass, the plate covers the Lilium’s top with the shape of the lily that gives the inspiration for the speaker’s name. You can see the passive radiator moving through the transparency, while infra-low frequencies vibrations invade the pavement, leaving the sound free to spread in the air.

THE STRUCTURE

Lilium is a loudspeaker system made up by two separate tuned enclosure, all totally independent from each other. The main full-range enclosure benefits from the use of the para-aperiodic Stealth reflex™ tuning system. The infra-low frequencies reproduction enclosure is implemented with our patented decoupling system Zero Vibration Transmission™, with the removal residual vibration system Tuned Mass Damper™ and with an up firing passive radiator.

BINDING POST

The terminal plates for connections allow tri-amplification and are located on two separate plates, to further underline the total independence of the front and rear cabinets.

SYSTEM

3.5 way para-aperiodic vented box

LOUDSPEAKERS

Tw: H28 XTR-04 DAD Arrow Point, Ø 28 mm
Md: M18 XTR-04 Neodymium Magnet System, Ø 180 mm
W: 3 x W18XTR-16, Ø 180 mm
Sw: SW26 XT-08, Ø 260 mm

CROSS-OVER

55Hz - 150Hz - 200Hz – 3000Hz

FREQUENCY RESPONSE

20 Hz – 35.000 Hz, Stealth reflex included

SENSITIVITY

92 db SPL (2.83V/1 m)

NOMINAL IMPEDANCE

4 ohm

SUGGESTED AMPLIFIER POWER OUTPUT

100 – 800 W, without clipping

LONG-TERM MAX INPUT VOLTAGE (IEC 268-5)

30 V rms

DIMENSIONS (HxWxD)

1600 x 491 x 705 mm
63 x 19,3 x 27,7 in

WEIGHT

103 Kg ea - net weight
227 Ib ea - net weight
