The 851C uses audiophile grade components throughout and incorporates our most advanced technologies to ensure it plays music perfectly. Your discs are spun on our own audio-only transport and coupled with our S3 servo to give error-free data retrieval and jitter minimisation. Our ultra-rigid metal construction also ensures components are isolated and free from vibration.

DIGITAL TO ANALOGUE CONVERTERS
Dual Analog Devices AD1955 24-bit DACs

DIGITAL FILTER
Analog Devices Black Fin ADSP-BF532 32 bit DSP performing 2nd Generation ATF2 upsampling to 24-bit/384kHz. Linear Phase, Minimum phase or Steep modes.

ANALOGUE FILTER
2 Pole Fully Differential Linear Phase Bessel filter

DIGITAL INPUT 1
S/PDIF 75 Ohms or TosLink optical

DIGITAL INPUT 2
S/PDIF 75 Ohms or TosLink optical

AES/EBU INPUT
XLR balanced 110 Ohms per phase

USB AUDIO INPUT
USB Type B conforming to Audio profile 1.0 or 2.0 (user selectable)

AUDIO OUTPUTS
Balanced XLR and unbalanced RCA analogue audio outputs

COMPATIBILITY
USB 1.0 16-24 bit, 32-96kHz USB 2.0 16-24 bit, 32-192kHz TosLink 16-24 bit, 32-96kHz S/PDIF and AES/EBU 16-24 bits 32-192kHz CD playback is intrinsically limited to 16-bits 44.1kHz

THD (UNWEIGHTED) @ 1KHHZ 0DBFS
< 0.0004%

THD (UNWEIGHTED) @ 1KHZ -10DBFS
< 0.0004%

THD (UNWEIGHTED) @ 20KHZ 0DBFS
< 0.0007%

IMD (19/20KHZ) 0DBFS
< 0.0002%

LINEARITY @ -90DBFS
+/- 0.2dB

LINEARITY @ -120DBF
+/- 0.4dB

STOP-BAND REJECTION (>24KHZ)
> 120dB

TOTAL CORRELATED JITTER
< 60pS for all digital inputs, CD playback and USB 2.0 < 180pS for USB 1.0

CROSSTALK @1KHZ
< -130dB

CROSSTALK @20 KHZ
< -114dB

OUTPUT IMPEDANCE
< 50 Ohms

0DB FS OUTPUT
2.2Vrms (2.2Vrms each phase for the balanced output)

MAX. POWER CONSUMPTION
40W

IDLE CONSUMPTION
8W

STANDBY POWER CONSUMPTION
< 0.5W

COLOUR
Black or silver

DIMENSIONS (WXHXD)
430 x 115 x 360mm (16.9 x 4.5 x 14.7”)

WEIGHT
10.0Kg (22lbs)
