AMPLIFIER

• FTC
• 7 x 140W
• Full Disclosure Power (all channels driven simultaneously at full bandwidth at rated distortion)
• 7 x 80W
• IHF Dynamic Power
•
• 8 Ohms
• 160W (22.0BW)
• 4 Ohms
• 260W (24.1dBW)
• Total harmonic distortion at rated power
• <0.08%
• IM distortion at rated power
• <0.08%
• Damping factor, 8 Ohms
• >60
• Input sensitivity and impedance
• 1.15V (ref. 8 Ohms, VOL at 0dB)
• Frequency response
• ±0.8dB (ref. 1kHz, 20Hz-20kHz)
• Signal/noise ratio
• >92dB (ref. rated power at 8 Ohms, A-Weighted)
• Signal/noise ratio
• >82dB (ref. 1W at 8 Ohms, A-Weighted)

PREAMPLIFIER

• Frequency response
• ±0.5dB (ref. 20Hz – 20kHz)
• Signal-to-noise ratio
• >88dB (ref. 2V, A-Weighted)
• Total harmonic distortion
• <0.01%
• Input sensitivity
• 330mV (ref. 2V)
• Maximum output level
• >4V

POWER CONSUMPTION

• Standby power
• <0.5W
• Idle Power
• >70W (120V version only)
•
• >63W (230V version only)

MDC UPGRADE MODULES

MDC Upgrade Modules included in this unit

• Video
• VM300(With BluOS)
• Audio
• AM230

WEIGHT & DIMENSIONS

• Unit Dimensions (W x H x D)
• 435 x 172 x 425mm (Gross)*
•
• 17 1/8 x 6 13/16 x 16 3/4″**
• Net Weight
• 20.5kg (45.2lb)
• Shipping Weight
• 24.2kg (53.4lb)
