Specifications

Model

Coda W

Drive units

Uni-Q Driver Array:
HF: 25 mm (1 in.) aluminium dome
LF/MF: 130 mm (5.25 in.) magnesium/aluminium alloy cone

Frequency range (-6dB) measured at 85dB/1m

38Hz - 20kHz
*Depends on EQ Settings

Frequency response (±3dB) measured at 85dB/1m

41Hz - 20kHz
*Depends on EQ Settings

Amplifier output power (per speaker)

LF: 70W HF: 30W

Amplifier class (per speaker)

LF: Class D HF: Class D

Max SPL measured at 1m

102 dB

Wireless streaming features

Bluetooth 5.4
aptX Adaptive™, aptX Lossless™

Source resolution

Optical up to 96kHz/24bit
USB Type C up to 192kHz/24bit
HDMI up to 1.411 Mbps PCM
*Depends on source resolution

Interspeaker connection

Wired: all sources resampled to 96kHz/24bit PCM

Dimensions (H x W x D per speaker)

285 x 168 x 268 mm (11.2 x 6.6 x 10.55 in.)

Weight (per set)

11.3kg

Power input

100 – 240VAC 50/60Hz

Power consumption

200W (operating power)
<0.5W (standby power)

Primary speaker

Inputs

HDMI
Optical
USB Type C
RCA (Without Phono stage)
RCA (With Phono stage)
USB Type C (interspeaker)
Bluetooth

Output

RCA Subwoofer output
USB Type C (interspeaker)
USB Type C (5V DC)

Secondary speaker

Inputs

USB Type C (interspeaker)
