01_

The best power-amplifier we have ever made.

Edge W is made to be played loud. When you do turn it up, expect nothing but a dynamic and punchy sound that captures all the musicality of your songs. With just 14 hand-picked components, Edge W has one of the cleanest signal paths available. It delivers our breath-taking, unadulterated British sound – nothing added, nothing taken away.

02_

Powerfully subtle.

For all its power, Edge W is remarkably detailed. The sound is finely balanced, with a musical depth and clarity that comes through with every note. It’s all down to how we chose the componentry inside – nothing was picked on price, specs or measured performance. We listened carefully. And created our system with components that simply sounded the best. The end result is a power amplifier that truly brings an original recording to life like no other.

03_

Just 14 components in the signal path.

Although minimal in its exterior design, Edge W has some complex audio engineering inside. To remove the barriers between you and your music, we have worked hard to minimise the number of components in the signal path.

As a result, Edge W delivers a more faithful reproduction of the original recording; an impressively detailed three-dimensional sound, with striking staging and focus.

CONTINUOUS POWER OUTPUT

100W RMS into 8 Ohms; 200W RMS into 4 Ohms

THD (UNWEIGHTED)

<0.002% 1kHz at rated power (8 Ohms); <0.02% 20Hz – 20kHz at rated power (8 Ohms)

FREQUENCY RESPONSE

<3Hz – >80kHz +/-1dB

S/N RATIO (REF 1W INTO 8 OHM)

>93 dB

CROSSTALK @ 1KHZ

< -100dB

S/N RATIO (REF FULL POWER)

>113 dB

INPUT SENSITIVITY

Input A1-A2 (unbalanced) 1.09V RMS

INPUT IMPEDANCES

Input A3 (balanced) 47k Ohm; Input A1-A2 (unbalanced) 47k Ohm

INPUTS

Balanced, Unbalanced

OUTPUTS

Speakers, Loop out

MAX POWER CONSUMPTION

1000W

STANDBY POWER CONSUMPTION

<0.5W

DIMENSIONS

150 x 460 x 405mm (5.9 x 18.1 x 15.9")

WEIGHT

23.6kg (51.9lbs)

IN THE BOX

Edge W Power Amplifier; 1.5M Power Lead; Edge Link Cable; Edge W User Manual
