Cambridge Audio CXN

DAC
Dual Wolfson WM8740 24-bit DACs
DIGITAL FILTER
2nd Generation ATF2 up-sampling to 24-bit/384khz
ANALOGUE FILTER
2-Pole Dual Differential Bessel
USB AUDIO INPUT
USB Type B conforms to USB Audio profile 1.0 or 2.0 (user selectable)
DIGITAL AUDIO INPUTS
S/PDIF Coaxial and TOSLINK Optical)
ANALOGUE AUDIO OUTPUTS
Balanced XLR and unbalanced RCA analogue
DIGITAL AUDIO OUTPUTS
S/PDIF Coaxial and TOSLINK Optical
COMPATIBILITY
UPnP, Local USB media, USB audio 1.0 and 2.0, S/PDIF Toslink and Coaxial, Airplay 2, Chromecast built-in , Internet radio, Spotify Connect, TIDAL, Qobuz, Bluetooth aptX via BT100 Bluetooth receiver (not supplied)
AUDIO FORMATS
ALAC, WAV, FLAC, AIFF, DSD (x64), WMA, MP3, AAC, HE AAC, AAC+, OGG Vorbis
ETHERNET
IEEE 802.3, 10 Base-T or 100 Base-T
WI-FI
IEEE 802.11 b/g or n (2.4GHz)
MAX POWER CONSUMPTION
30W
STANDBY POWER CONSUMPTION
<0.5W
REMOTE CONTROL
Yes
DIMENSIONS
85 x 430 x 305mm (3.4 x 16.9 x 12.2”)
WEIGHT
3.5Kg (7.7lbs)

Cambridge Audio CXA 61

POWER OUTPUT
60W RMS into 8 Ohms, 90W RMS into 4 Ohms
DAC
ESS Sabre ES9010K2M
FREQUENCY RESPONSE
<5Hz– 60kHz +/-1dB
ANALOGUE AUDIO INPUTS
4 x RCA, 1 x 3.5mm MP3 input (front panel)
DIGITAL AUDIO INPUTS
1 x S/PDIF coaxial, 2 x TOSLINK optical, 1 x USB audio, Bluetooth (integrated)
COMPATIBILITY
TOSLINK optical: 16/24bit 32-96kHz PCM only, S/PDIF coaxial: 16/24bit 32-192kHz PCM only, USB: audio profile =1.0/2.0 (default 2.0), up to 32bit 384kHz PCM, up to DSD256 or DoP256, Bluetooth: 4.2 A2DP/AVRCP supporting up to aptX HD (24bit 48kHz)
BLUETOOTH APTX HD RECEIVER BUILT-IN
Yes
ROON TESTED
Yes
OUTPUTS
Speakers A+B, 3.5mm Headphone, Preamp Output, Subwoofer Output
REMOTE CONTROL
Yes
MAX POWER CONSUMPTION
600W
STANDBY POWER CONSUMPTION
<0.5W
DIMENSIONS (H X W X D)
115 x 430 x 341mm (4.5 x 16.9 x 13.4”)
WEIGHT
8.3kg (18.3lbs)
