The most powerful amplifier in the AX range offers a massive 100 watts per channel, a dedicated subwoofer speaker output for improving bass and two sets of speaker outputs. It also features analogue inputs, digital inputs, a phono stage, an FM/AM receiver with RDS and a 3.5mm input. In addition, the built-in bluetooth receiver allows you stream your favourite music from your smartphone, tablet or PC.
100 watts (into 8Ω)
<0.01% @ 1kHz, 80% of rated power <0.15% 20Hz - 20kHz, 80% of rated power
FREQUENCY RESPONSE (-1DB)
5Hz - 50kHz
S/N RATIO (REF 1W)
POWER AMP DAMPING FACTOR
STANDBY POWER CONSUMPTION
MAX. POWER CONSUMPTION
Shelving, ultimate boost/cut +/- 10dB @ 100Hz and 20kHz
200Hz 2nd order L+R Level follows volume setting
PCM 16-24-bit S/P DIF Co-axial 32-192kHz TOSlink Optical 32-192kHz
110 x 430 x 340mm (4.3 x 16.9 x 13.4”)
5.0 A2DP/AVRCP supporting SBC
European AM (522-1629kHz) FM (87.5-108MHz) / US AM (530-1710kHz) FM (87.5-108MHz)
FM 75 ohms, Coaxial. AM 300 ohms wire loop/ single wire
SIGNAL TO NOISE (TUNER)
60dB typical (FM)
<0.4% @ 1kHz 50kHz deviation (FM mono) <0.6% @ 1kHz 50kHz deviation (FM stereo)
IN THE BOX
AXR100 Stereo Receiver, Power Cable, Remote Control, 2 x AAA Batteries
